Building a 4-Layer Agentic Architecture for Claude Code

The Problem

#

After months of building Claude Code extensions – agents, skills, commands, hooks, MCP servers – I had a growing collection of powerful tools with no coherent entry point. Want to pull all repos? Run a shell script. Want to check infrastructure health? Ask Claude and hope it knows which command to use. Want to automate a browser task? Figure out whether to use the MCP plugin or write a script.

Every new capability added more cognitive load. The tools were good individually, but the system was incoherent.

The Inspiration

#

IndyDevDan’s Bowser framework introduced a clean mental model: composable layers where each has a single responsibility and can be entered independently. His stack was designed for browser automation, but the pattern is universal.

The insight: you don’t need one tool that does everything. You need layers that compose.

The Architecture

#

Four layers, each with a clear boundary:

Layer 1: Justfile (Human CLI)

#

Just is a command runner – think make without the build system baggage. A single justfile at the workspace root wraps all existing shell scripts and adds new utilities:

1
2
3
4
5

just pull        # Start of session - pull all repos
just end         # End of session - audit + commit + push
just status      # Show repos with uncommitted changes
just health      # List infrastructure health check stories
just browse      # List browser automation stories

Key decision: The justfile wraps existing scripts – it doesn’t replace them. just pull calls ./start-pull-all-repos.sh under the hood. Zero migration cost, instant unified interface.

Layer 2: Commands (Agent Interface)

#

Commands are markdown files with YAML frontmatter that define structured prompts for Claude. They’re the bridge between human intent and agent execution:

• /mx-homelab-health pihole-ha – Parse a YAML health check story, SSH into servers, run checks, report pass/fail
• /mx-bowser homelab-services – Parse a browser story YAML, write Playwright scripts, execute, report results

Commands are imperative – they tell the agent exactly what to do and how to report results.

Layer 3: Skills (Passive Context)

#

Skills are knowledge that Claude loads automatically when it detects relevance. They don’t execute anything – they inform:

• mx:health-check triggers on “homelab health”, “service status” – tells Claude about the YAML story system
• mx:playwright-bowser triggers on “browse website”, “take screenshot” – tells Claude to prefer CLI over MCP

Skills are declarative – they teach the agent what’s available and how it works.

Layer 4: Agents (Autonomous Execution)

#

The actual execution layer – Claude’s Task tool spawning specialized subagents, MCP server tools, or direct Bash commands. This layer already existed; the architecture just makes the entry points clearer.

YAML-Driven Stories

#

Both health checks and browser automation use the same pattern: declarative YAML files that describe what to check, not how to check it.

Infrastructure Health Checks

#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15

name: pihole-ha
description: Pi-hole HA cluster health
severity: critical

targets:
  - host: <DNS-PRIMARY-IP>
    role: dns1
  - host: <DNS-SECONDARY-IP>
    role: dns2

checks:
  - name: FTL service running
    type: ssh_command
    command: "systemctl is-active pihole-FTL"
    expect: "active"

Four stories cover the critical infrastructure: Pi-hole HA, Caddy HA, Proxmox cluster, and Docker service stacks. Each story defines targets (hosts) and checks (commands with expected output).

Browser Automation Stories

#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

name: homelab-services
description: Verify homelab web UIs are accessible

stories:
  - name: "n8n web UI loads"
    steps:
      - action: navigate
        url: "http://<DOCKER-HOST>:5678"
      - action: assert_title
        text: "n8n"
      - action: screenshot
        path: /tmp/pw-n8n.png

Same idea, different domain. The orchestrator command reads the YAML, generates a Playwright script, executes it, and reports results.

CLI-First Browser Automation

#

This was the most interesting design decision. The Bowser framework’s insight: MCP tool calls carry schema overhead that burns tokens. Every browser_navigate, browser_click, browser_snapshot call includes the full tool schema in the conversation context.

The alternative: write a Playwright script to /tmp/pw-task.mjs and run it with node. One Bash call instead of 5-10 MCP calls. Same Playwright engine, dramatically fewer tokens.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

import { createRequire } from 'module';
const require = createRequire('<PLAYWRIGHT-INSTALL-PATH>');
const { chromium } = require('playwright');

const browser = await chromium.launch({ headless: true });
const page = await browser.newPage();
try {
  await page.goto('https://example.com');
  console.log(await page.title());
  await page.screenshot({ path: '/tmp/pw-result.png' });
} finally {
  await browser.close();
}

The createRequire pattern is worth noting – it solves a WSL2-specific problem where npm install -g needs root permissions. Instead, Playwright lives in a local project directory, and scripts resolve it via Node’s module system.

MCP mode is kept as a fallback for when you need interactive DOM inspection or step-by-step debugging. Two modes, one engine, pick the right one for the task.

What I Learned

#

Layers compose better than monoliths

#

The temptation with AI tools is to build one mega-skill that handles everything. The 4-layer approach works better because each layer can evolve independently. Adding a new health check? Just drop a YAML file. New browser test? Same pattern. No skill code changes needed.

Declarative beats imperative for story-driven automation

#

YAML stories are the real unlock. They’re version-controlled, diffable, reviewable, and composable. The same pattern works for infrastructure health, browser testing, and potentially deployment validation, security scanning, or backup verification.

Token efficiency matters in agentic workflows

#

Every MCP tool call in the conversation context costs tokens. For repetitive operations (navigate, click, fill, assert), writing a script and executing it once is dramatically cheaper than individual tool calls. The CLI-first pattern isn’t just faster – it’s cheaper.

Wrap, don’t replace

#

The justfile wraps existing shell scripts instead of rewriting them. This is the right approach for introducing a new layer – zero migration risk, immediate value, and the old tools still work exactly as before.

What’s Next

#

The YAML story pattern could extend to:

• Deployment validation stories – verify a service is healthy after deploy
• Security audit stories – check SSL certs, open ports, firewall rules
• Backup verification stories – confirm backup freshness and restorability

Each would follow the same pattern: YAML definition, command orchestrator, skill for context, justfile recipe for humans.
