Adding Proxmox Cluster Monitoring to Grafana

The Goal

#

Add all 4 Proxmox VE cluster nodes (pve-mini2, pve-mini3, pve-mini5, pve-mini6) to the existing Prometheus/Grafana stack on LXC 30194. The monitoring stack already covered Graylog, Windows desktop, and PAN-OS firewall metrics – Proxmox was the last major gap.

Approach: pve-exporter vs node_exporter

#

I evaluated two options:

1. node_exporter on each Proxmox host – gives OS-level metrics (CPU, RAM, disk, network) but misses Proxmox-specific data like VM/CT status, storage pools, and cluster quorum.
2. pve-exporter (API-based) – a single relay container that queries the Proxmox VE REST API and exposes all cluster, node, storage, and guest metrics. One container monitors the entire cluster.

I chose pve-exporter because it provides Proxmox-native metrics (guest status, storage pool usage, cluster health) without installing anything on the Proxmox hosts themselves. The trade-off is slightly less OS-level detail, but for cluster oversight this is the better fit.

Implementation

#

PVE API Token

#

Created a dedicated API user and token on the Proxmox cluster:

1
2
3
4

# On any Proxmox node
pveum user add prometheus@pve
pveum aclmod / -user prometheus@pve -role PVEAuditor
pveum user token add prometheus@pve exporter --privsep 0

Key lesson: the token was initially created with --privsep 1 (default), which caused 403 Forbidden errors on /api2/json/cluster/status despite the correct role assignment. Switching to --privsep 0 (token inherits user permissions) resolved it. The PVEAuditor built-in role provides read-only access to all cluster data.

Docker Compose

#

Added pve-exporter to the existing stack:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

pve-exporter:
  image: prompve/prometheus-pve-exporter:3
  container_name: pve-exporter
  restart: unless-stopped
  environment:
    - TZ=America/Los_Angeles
    - PVE_USER=${PVE_USER}
    - PVE_TOKEN_NAME=${PVE_TOKEN_NAME}
    - PVE_TOKEN_VALUE=${PVE_TOKEN_VALUE}
    - PVE_VERIFY_SSL=${PVE_VERIFY_SSL}
  ports:
    - "9221:9221"

Prometheus Scrape Jobs

#

Two scrape jobs using the same multi-target relay pattern as snmp-exporter:

• pve-cluster: Scrapes one node (192.168.30.202) with cluster=1, node=0 for cluster-wide metrics
• pve-nodes: Scrapes all 4 nodes individually with cluster=0, node=1 for per-node metrics

The per-node job uses relabel rules to assign friendly instance names (pve-mini2, pve-mini3, etc.) – the same 4th-rule pattern established for the SNMP firewall job.

Grafana Dashboard

#

Created a 21-panel dashboard across 5 sections:

Template variables for node (multi-select) and guest_type (All/VMs/CTs) enable filtering.

Alert Rules

#

Added 5 Proxmox-specific alerts:

The “Critical Guest Down” alert uses an and on(id) join between pve_up and pve_onboot_status to only fire for guests configured to auto-start.

Challenges and Fixes

#

PVE Token Authentication (privsep)

#

The biggest debugging effort was the 403 errors with --privsep 1. Even after assigning PVEAuditor to both the user AND the token, API calls failed. Recreating the token with --privsep 0 fixed it immediately. This seems to be either a PVE bug or an undocumented behavior where privilege separation doesn’t fully propagate token ACLs.

Grafana Folder Caching

#

The Proxmox dashboard initially landed in the “Graylog Monitoring” folder instead of the “Proxmox” folder. The root cause was that the server still had the old dashboards.yml with a single catch-all provider. Even after a Grafana volume reset, the old config was still being used. The fix required both deploying the correct per-folder dashboards.yml and resetting the Grafana data volume.

Deployment File Sync

#

The scp -r of the provisioning directory didn’t fully sync all files – the rules.yml on the server was missing the Proxmox alert group, and the dashboard JSON didn’t copy into the Proxmox/ subdirectory. Had to SCP individual files and verify on the server. Lesson: always verify deployed files match local copies after bulk SCP operations.

Final Verification

#

After deployment, all systems verified healthy:

• 12/12 Prometheus targets UP (including pve-cluster + 4 pve-nodes)
• 6/6 containers running (prometheus, grafana, opensearch-exporter, snmp-exporter, node-exporter, pve-exporter)
• Dashboard in Proxmox folder with 21 panels rendering correctly
• 13 alert rules active (4 Graylog + 4 mx-fw + 5 Proxmox)
• All 4 Proxmox nodes reporting metrics with friendly instance names

Files Changed

#

Key Takeaways

#

1. pve-exporter is excellent for cluster-level monitoring – one container covers all nodes, VMs, CTs, and storage with no agent installation on Proxmox hosts
2. Always use --privsep 0 for pve-exporter API tokens unless you have a specific reason for privilege separation
3. Grafana folder assignments are cached in SQLite – changing dashboards.yml folder config requires a volume reset (docker volume rm), not just a restart
4. Verify deployed files on the server – bulk SCP can silently skip files, especially in subdirectories
5. The multi-target relay pattern (same as snmp-exporter) works seamlessly for pve-exporter with the standard 3-rule relabel + 4th rule for friendly names
