Deploying Wazuh XDR with Graylog Integration

The Challenge

#

I needed a unified security monitoring solution that could:

1. Provide endpoint detection and response (XDR) capabilities
2. Integrate with my existing Graylog centralized logging infrastructure
3. Scale from a single-node deployment to multi-node if needed
4. Work with my existing OpenClaw threat intelligence feeds

The Solution

#

Wazuh Single-Node Stack

#

Deployed Wazuh as a Docker-based single-node stack. The single-node architecture includes:

• Wazuh Manager: Core HIDS/XDR engine
• Wazuh Indexer: OpenSearch-based storage
• Wazuh Dashboard: Kibana-based UI

Graylog Integration via Rsyslog

#

Rather than replacing Graylog, I integrated Wazuh alerts into my existing logging pipeline:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

# /etc/rsyslog.d/wazuh-graylog.conf
# Forward Wazuh alerts to Graylog via syslog
module(load="imfile")

input(type="imfile"
      File="/var/ossec/logs/alerts/alerts.json"
      Tag="wazuh-alerts"
      Severity="info"
      Facility="local0")

local0.* @@<GRAYLOG_SERVER>:1514;RSYSLOG_SyslogProtocol23Format

Pipeline Creation Scripts

#

Created Python scripts to automate Graylog configuration:

Pipeline Creator - Sets up extractors and processing rules for Wazuh JSON:

1
2
3
4
5

# Key fields extracted:
# - rule.level (severity 0-15)
# - rule.description (alert message)
# - agent.name (source host)
# - data.* (event-specific data)

Dashboard Creator - Generates Graylog dashboards with:

• Alert severity distribution (pie chart)
• Top 10 triggered rules (bar chart)
• Agent activity timeline (histogram)
• Critical alerts table (>= level 10)

What I Learned

#

1. JSON Log Shipping is Tricky

#

Wazuh writes alerts as JSON Lines format, but rsyslog’s imfile module treats each line as a message. This works well for Graylog’s JSON extractor, but you need to ensure:

• File permissions allow rsyslog to read the alerts file
• Log rotation doesn’t break the file watcher

2. OpenClaw Integration Adds Value

#

Custom rules referencing OpenClaw threat feeds (openclaw_rules.xml) provide:

• Known malicious IP detection
• Suspicious domain lookups
• File hash matching against threat intel

3. Single-Node is Fine for Homelab

#

The three-container stack (manager, indexer, dashboard) runs comfortably on:

• 4 vCPUs
• 8GB RAM
• 50GB storage

For a homelab with <20 agents, this is more than sufficient.

Architecture

#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21

┌─────────────────────────────────────────────────────────────┐
│                    Security Monitoring                       │
├─────────────────────────────────────────────────────────────┤
│                                                             │
│  ┌─────────┐    ┌─────────┐    ┌─────────┐                 │
│  │ Agents  │───▶│ Wazuh   │───▶│ Wazuh   │                 │
│  │ (hosts) │    │ Manager │    │ Indexer │                 │
│  └─────────┘    └────┬────┘    └─────────┘                 │
│                      │                                      │
│                      │ alerts.json                          │
│                      ▼                                      │
│               ┌──────────────┐                              │
│               │   rsyslog    │                              │
│               └──────┬───────┘                              │
│                      │ syslog/tcp:1514                      │
│                      ▼                                      │
│               ┌──────────────┐                              │
│               │   Graylog    │◀── Unified Log View          │
│               └──────────────┘                              │
│                                                             │
└─────────────────────────────────────────────────────────────┘

Files Created

#

Next Steps

#

1. Deploy Wazuh agents to all LXC containers
2. Create alerting rules in Graylog for critical Wazuh events
3. Integrate with Discord notifications for real-time alerts
4. Explore Wazuh’s vulnerability detection module

Takeaway: Wazuh provides enterprise-grade XDR capabilities that integrate well with existing logging infrastructure. The rsyslog bridge to Graylog gives you the best of both worlds - specialized security analytics in Wazuh and unified log correlation in Graylog.
