High-Availability Pi-hole DNS with Keepalived VRRP

Table of Contents

Homelab Security - This article is part of a series.

Part : This Article

Part : Protecting Vaultwarden Behind Caddy with Cloudflare Proxy

Overview
#

DNS is the backbone of your network. When your Pi-hole goes down, every device in your home loses internet access. Websites won’t load. Apps stop working. Smart home devices go offline. It’s a single point of failure that brings everything to a halt.

This tutorial shows you how to build a resilient DNS infrastructure using two Pi-hole servers with automatic failover. If one server dies, the other seamlessly takes over in under 15 seconds — without any manual intervention.

What you’ll build:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
                    Client Devices
                          ↓
                 Firewall DNS Proxy
                          ↓
              Pi-hole VIP (<DNS_VIP>)
                  ↙          ↘
         DNS-Primary         DNS-Secondary
      <DNS_PRIMARY_IP>    <DNS_SECONDARY_IP>
       Priority: 200       Priority: 100
            ↓                    ↓
      Health Check          Health Check
      (every 5 sec)         (every 5 sec)
            ↓                    ↓
    VIP ACTIVE when       Takes VIP when
    healthy (MASTER)      Primary fails

Key features:

Automatic failover - VIP moves to backup server when primary fails
Health monitoring - Checks FTL service, port 53, DNS resolution
Discord notifications - Real-time alerts on state changes
Staggered updates - Never update both servers simultaneously
Zero client configuration - Clients always use the same VIP address

Prerequisites
#

Before starting, you need:

Two Linux servers - LXC containers work great (1GB RAM minimum each)
Pi-hole v6 - Already installed and configured on both servers
SSH access - Ability to deploy files and restart services
Discord webhook (optional) - For failover notifications
Static IPs - Both servers need fixed IP addresses on the same subnet
VIP address - Available IP on the same subnet for the floating virtual IP

Network requirements:

All three IPs (primary, secondary, VIP) must be on the same subnet
VIP should not conflict with DHCP ranges or other static assignments
Firewall/router must allow VRRP multicast traffic (protocol 112)

Architecture Diagram
#

The high-availability setup uses VRRP (Virtual Router Redundancy Protocol) to manage a floating IP address that automatically moves between servers based on health status.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
┌─────────────────────────────────────────────────────────────┐
│                    Your Network Devices                      │
│  (phones, laptops, servers, IoT devices)                     │
└────────────────────┬────────────────────────────────────────┘
                     │ DNS queries to <DNS_VIP>
                     ↓
         ┌───────────────────────┐
         │  Firewall DNS Proxy   │
         │  (Optional Layer)     │
         └───────────┬───────────┘
                     │
                     ↓
         ┌───────────────────────┐
         │  Virtual IP (VIP)     │
         │  <DNS_VIP>            │
         │  (Floating Address)   │
         └───────────┬───────────┘
                     │
        ┌────────────┴────────────┐
        │  keepalived VRRP        │
        │  Manages VIP Location   │
        └────────────┬────────────┘
                     │
         ┌───────────┴───────────┐
         │                       │
    MASTER State           BACKUP State
         ↓                       ↓
┌─────────────────┐     ┌─────────────────┐
│  DNS-Primary    │     │  DNS-Secondary  │
│ <DNS_PRIMARY_IP>│     │<DNS_SECONDARY_IP>│
│  Priority: 200  │     │  Priority: 100  │
├─────────────────┤     ├─────────────────┤
│ Pi-hole v6      │     │ Pi-hole v6      │
│ pihole-FTL      │     │ pihole-FTL      │
├─────────────────┤     ├─────────────────┤
│ Health Check    │     │ Health Check    │
│ Every 5 sec     │     │ Every 5 sec     │
│ 3 fails = -150  │     │ Watching for    │
│ priority        │     │ Primary failure │
└─────────────────┘     └─────────────────┘
         │                       │
         └───────┬───────────────┘
                 ↓
         Discord Webhook
         (State Change Alerts)

How failover works:

Both servers run keepalived with VIP configured
DNS-Primary has priority 200, DNS-Secondary has priority 100
Health check runs every 5 seconds on both servers
If DNS-Primary health check passes: VIP stays on DNS-Primary (MASTER)
If DNS-Primary fails 3 consecutive checks (15 seconds): Priority drops from 200 → 50
DNS-Secondary sees DNS-Primary priority < 100, claims VIP (becomes MASTER)
Discord notification sent on state change
When DNS-Primary recovers: Priority returns to 200, reclaims VIP

Step 1: Install Keepalived
#

Install keepalived on both Pi-hole servers:

1
2
3
4
5
6
7
# SSH to primary
ssh user@<DNS_PRIMARY_IP>
sudo apt update && sudo apt install -y keepalived

# SSH to secondary
ssh user@<DNS_SECONDARY_IP>
sudo apt update && sudo apt install -y keepalived

Verify installation:

1
2
keepalived --version
# Should show version 2.2.x or newer

Step 2: Create Health Check Script
#

The health check script verifies Pi-hole is actually working, not just running. Create this script on both servers.

File: /etc/keepalived/check_pihole.sh

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
#!/bin/bash
set -euo pipefail
#
# Pi-hole Health Check Script for Keepalived
# Verifies that Pi-hole FTL service is running and responding to DNS queries
#
# Exit codes:
#   0 = Pi-hole is healthy (keepalived continues as MASTER/BACKUP)
#   1 = Pi-hole is unhealthy (keepalived reduces priority)
#

# Check if pihole-FTL service is active
if ! systemctl is-active --quiet pihole-FTL; then
    logger -t keepalived-healthcheck "FAILED: pihole-FTL service is not running"
    exit 1
fi

# Check if FTL is listening on port 53 (DNS)
if ! ss -tulpn | grep -q ':53.*pihole-FTL'; then
    logger -t keepalived-healthcheck "FAILED: pihole-FTL not listening on port 53"
    exit 1
fi

# Perform actual DNS query test using dig
# Query DNS infrastructure domains to verify DNS resolution is working
# Uses redundant targets to avoid false positives from single-site outages
if command -v dig &> /dev/null; then
    # Try Google's DNS infrastructure first (dns.google = 8.8.8.8)
    if ! timeout 1.0 dig @127.0.0.1 +short +tries=1 +time=1 dns.google &> /dev/null; then
        # First query failed, try Cloudflare as fallback (one.one.one.one = 1.1.1.1)
        if ! timeout 1.0 dig @127.0.0.1 +short +tries=1 +time=1 one.one.one.one &> /dev/null; then
            logger -t keepalived-healthcheck "FAILED: DNS query test failed (both targets unreachable)"
            exit 1
        fi
    fi
else
    # Fallback to nc if dig is not available
    if ! echo -e "q\n" | timeout 1.0 nc -u 127.0.0.1 53 &> /dev/null; then
        logger -t keepalived-healthcheck "FAILED: Port 53 connectivity test failed"
        exit 1
    fi
fi

# All checks passed
exit 0

Deploy and set permissions:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
# Copy to both servers
scp check_pihole.sh user@<DNS_PRIMARY_IP>:/tmp/
scp check_pihole.sh user@<DNS_SECONDARY_IP>:/tmp/

# On each server, move to final location
ssh user@<DNS_PRIMARY_IP> "sudo mv /tmp/check_pihole.sh /etc/keepalived/ && \
                            sudo chmod 750 /etc/keepalived/check_pihole.sh && \
                            sudo chown root:root /etc/keepalived/check_pihole.sh"

ssh user@<DNS_SECONDARY_IP> "sudo mv /tmp/check_pihole.sh /etc/keepalived/ && \
                              sudo chmod 750 /etc/keepalived/check_pihole.sh && \
                              sudo chown root:root /etc/keepalived/check_pihole.sh"

Why redundant DNS queries?

Using multiple targets (dns.google + one.one.one.one) prevents false positives. If Google’s DNS is briefly unreachable, Cloudflare provides a fallback. Both have 99.99%+ uptime SLAs. The health check only fails if both queries fail, indicating a real Pi-hole problem.

Step 3: Configure Keepalived (Primary)
#

Create keepalived configuration on DNS-Primary.

File: /etc/keepalived/keepalived.conf (on <DNS_PRIMARY_IP>)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
global_defs {
    router_id DNS_PRIMARY
    enable_script_security
    script_user root
}

vrrp_script check_pihole {
    script "/etc/keepalived/check_pihole.sh"
    interval 5        # Run every 5 seconds
    timeout 2         # Script must complete within 2 seconds
    fall 3            # Require 3 consecutive failures before declaring unhealthy
    rise 2            # Require 2 consecutive successes before declaring healthy
    weight -150       # Reduce priority by 150 when unhealthy
}

vrrp_instance DNS_HA {
    state MASTER                    # Initial state
    interface eth0                  # Network interface
    virtual_router_id 55            # Must match on both servers
    priority 200                    # Higher = preferred MASTER
    advert_int 1                    # Advertise every 1 second

    authentication {
        auth_type PASS
        auth_pass YourSecretPassword  # Change this! Must match on both servers
    }

    unicast_src_ip <DNS_PRIMARY_IP>   # This server's IP
    unicast_peer {
        <DNS_SECONDARY_IP>             # Peer server's IP
    }

    virtual_ipaddress {
        <DNS_VIP>/24                   # Virtual IP with subnet mask
    }

    track_script {
        check_pihole
    }

    notify "/etc/keepalived/keepalived-discord-notify.sh"
}

Key parameters explained:

Parameter	Value	Why
`priority`	200	Primary’s base priority (higher than secondary’s 100)
`weight`	-150	Drops priority to 50 when unhealthy (below secondary’s 100)
`fall`	3	Requires 15 seconds of failures (3 × 5 sec) before failover
`rise`	2	Requires 10 seconds of health (2 × 5 sec) before recovery
`virtual_router_id`	55	Arbitrary number, must match on both servers

Critical: The weight value must drop primary’s priority below secondary’s priority to trigger failover. If weight is too small (e.g., -50), the calculation becomes 200 - 50 = 150, which is still higher than secondary’s 100, preventing failover.

Step 4: Configure Keepalived (Secondary)
#

Create keepalived configuration on DNS-Secondary. Only 4 values change from primary config.

File: /etc/keepalived/keepalived.conf (on <DNS_SECONDARY_IP>)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
global_defs {
    router_id DNS_SECONDARY           # Changed: Different router ID
    enable_script_security
    script_user root
}

vrrp_script check_pihole {
    script "/etc/keepalived/check_pihole.sh"
    interval 5
    timeout 2
    fall 3
    rise 2
    weight -150
}

vrrp_instance DNS_HA {
    state BACKUP                      # Changed: Initial state BACKUP
    interface eth0
    virtual_router_id 55
    priority 100                      # Changed: Lower priority
    advert_int 1

    authentication {
        auth_type PASS
        auth_pass YourSecretPassword  # Same as primary
    }

    unicast_src_ip <DNS_SECONDARY_IP> # Changed: This server's IP
    unicast_peer {
        <DNS_PRIMARY_IP>              # Changed: Primary's IP
    }

    virtual_ipaddress {
        <DNS_VIP>/24
    }

    track_script {
        check_pihole
    }

    notify "/etc/keepalived/keepalived-discord-notify.sh"
}

Deploy configurations:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
# Copy configs to servers
scp keepalived-primary.conf user@<DNS_PRIMARY_IP>:/tmp/keepalived.conf
scp keepalived-secondary.conf user@<DNS_SECONDARY_IP>:/tmp/keepalived.conf

# Move to final location on each server
ssh user@<DNS_PRIMARY_IP> "sudo mv /tmp/keepalived.conf /etc/keepalived/keepalived.conf && \
                            sudo chmod 644 /etc/keepalived/keepalived.conf"

ssh user@<DNS_SECONDARY_IP> "sudo mv /tmp/keepalived.conf /etc/keepalived/keepalived.conf && \
                              sudo chmod 644 /etc/keepalived/keepalived.conf"

Validate syntax before starting:

1
2
3
4
5
6
7
# On primary
ssh user@<DNS_PRIMARY_IP> "sudo keepalived -t -f /etc/keepalived/keepalived.conf"

# On secondary
ssh user@<DNS_SECONDARY_IP> "sudo keepalived -t -f /etc/keepalived/keepalived.conf"

# Both should output: "Configuration is using : 0 Bytes"

Step 5: Discord Notifications (Optional)
#

Get instant alerts when failover occurs. This script sends color-coded Discord embeds on state changes.

Setup Discord webhook:

Go to your Discord server → Server Settings → Integrations
Create a new webhook, copy the URL
Replace <YOUR_WEBHOOK_ID>/<YOUR_WEBHOOK_TOKEN> in the script below

File: /etc/keepalived/keepalived-discord-notify.sh (deploy to both servers)

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
#!/bin/bash
set -euo pipefail
#
# Keepalived Discord Notification Script
# Sends formatted alerts to Discord webhook when VRRP state changes
#
# Usage: /etc/keepalived/keepalived-discord-notify.sh <STATE> <INSTANCE>
#

STATE=$1
INSTANCE=$2
WEBHOOK_URL="https://discord.com/api/webhooks/<YOUR_WEBHOOK_ID>/<YOUR_WEBHOOK_TOKEN>"

# Get system information
HOSTNAME=$(hostname)
FQDN=$(hostname -f)
IP_ADDRESS=$(ip -4 addr show eth0 | grep -oP '(?<=inet\s)\d+(\.\d+){3}' | head -1)
VIP_STATUS=$(ip addr show eth0 | grep -q "<DNS_VIP>" && echo "Active" || echo "Inactive")
TIMESTAMP=$(date -u +"%Y-%m-%dT%H:%M:%S.000Z")
READABLE_TIME=$(date "+%Y-%m-%d %H:%M:%S %Z")

# Determine color and emoji based on state
# Colors in decimal: Green=5763719, Yellow=16705372, Red=15548997
case "$STATE" in
    MASTER)
        COLOR=5763719
        EMOJI="🟢"
        TITLE="Pi-hole DNS - MASTER State"
        DESCRIPTION="**$HOSTNAME** has transitioned to **MASTER** state and is now serving DNS requests."
        ;;
    BACKUP)
        COLOR=16705372
        EMOJI="🟡"
        TITLE="Pi-hole DNS - BACKUP State"
        DESCRIPTION="**$HOSTNAME** has transitioned to **BACKUP** state and is on standby."
        ;;
    FAULT)
        COLOR=15548997
        EMOJI="🔴"
        TITLE="Pi-hole DNS - FAULT State"
        DESCRIPTION="**$HOSTNAME** has encountered a FAULT condition. Immediate attention required!"
        ;;
    *)
        COLOR=5793266
        EMOJI="ℹ️"
        TITLE="Pi-hole DNS - State Change"
        DESCRIPTION="**$HOSTNAME** state changed to: **$STATE**"
        ;;
esac

# Build Discord embed JSON payload
PAYLOAD=$(cat <<EOF
{
  "username": "Keepalived Monitor",
  "embeds": [{
    "title": "$EMOJI $TITLE",
    "description": "$DESCRIPTION",
    "color": $COLOR,
    "timestamp": "$TIMESTAMP",
    "fields": [
      {
        "name": "Hostname",
        "value": "\`$FQDN\`",
        "inline": true
      },
      {
        "name": "Server IP",
        "value": "\`$IP_ADDRESS\`",
        "inline": true
      },
      {
        "name": "VIP Status",
        "value": "\`$VIP_STATUS\`",
        "inline": true
      },
      {
        "name": "New State",
        "value": "\`$STATE\`",
        "inline": true
      },
      {
        "name": "VRRP Instance",
        "value": "\`$INSTANCE\`",
        "inline": true
      },
      {
        "name": "Time",
        "value": "\`$READABLE_TIME\`",
        "inline": true
      }
    ],
    "footer": {
      "text": "Keepalived VRRP Monitor | <YOUR_DOMAIN>"
    }
  }]
}
EOF
)

# Send to Discord webhook
curl -H "Content-Type: application/json" \
     -X POST \
     -d "$PAYLOAD" \
     "$WEBHOOK_URL" \
     --silent --output /dev/null

# Log to syslog
logger -t keepalived-notify "[$HOSTNAME] VRRP Instance $INSTANCE transitioned to $STATE state"

exit 0

Deploy:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
# Copy to both servers
scp keepalived-discord-notify.sh user@<DNS_PRIMARY_IP>:/tmp/
scp keepalived-discord-notify.sh user@<DNS_SECONDARY_IP>:/tmp/

# Set permissions
ssh user@<DNS_PRIMARY_IP> "sudo mv /tmp/keepalived-discord-notify.sh /etc/keepalived/ && \
                            sudo chmod 750 /etc/keepalived/keepalived-discord-notify.sh && \
                            sudo chown root:root /etc/keepalived/keepalived-discord-notify.sh"

ssh user@<DNS_SECONDARY_IP> "sudo mv /tmp/keepalived-discord-notify.sh /etc/keepalived/ && \
                              sudo chmod 750 /etc/keepalived/keepalived-discord-notify.sh && \
                              sudo chown root:root /etc/keepalived/keepalived-discord-notify.sh"

Step 6: Start Keepalived
#

Start keepalived on secondary first, then primary. This ensures clean startup without flapping.

Discord notifications showing keepalived MASTER and BACKUP state changes

1
2
3
4
5
6
7
8
# Start on secondary (BACKUP)
ssh user@<DNS_SECONDARY_IP> "sudo systemctl enable keepalived && sudo systemctl start keepalived"

# Wait 5 seconds
sleep 5

# Start on primary (MASTER)
ssh user@<DNS_PRIMARY_IP> "sudo systemctl enable keepalived && sudo systemctl start keepalived"

Check status:

1
2
3
4
5
6
7
8
# On primary - should show VIP active
ssh user@<DNS_PRIMARY_IP> "ip addr show eth0 | grep <DNS_VIP>"

# On secondary - should NOT show VIP
ssh user@<DNS_SECONDARY_IP> "ip addr show eth0 | grep <DNS_VIP>"

# Check keepalived logs
ssh user@<DNS_PRIMARY_IP> "sudo journalctl -u keepalived --since '5 minutes ago' --no-pager"

You should see Discord notifications for both servers: DNS-Secondary entering BACKUP state, DNS-Primary entering MASTER state.

Step 7: Stagger Automated Updates
#

Critical: Never update both Pi-hole servers simultaneously. If an update breaks DNS, you’ll have zero redundancy. Stagger updates by at least 3 days.

File: /etc/crontab (add to each server)

1
2
3
4
5
# On DNS-Primary - 1st of each month at 3:00 AM
0 3 1 * * root /usr/local/bin/pihole-auto-update.sh

# On DNS-Secondary - 4th of each month at 3:00 AM
0 3 4 * * root /usr/local/bin/pihole-auto-update.sh

Create update script:

File: /usr/local/bin/pihole-auto-update.sh (deploy to both servers)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
#!/bin/bash
set -euo pipefail
#
# Pi-hole Automatic Update Script
# Runs monthly updates and logs the results
#

LOGFILE="/var/log/pihole-auto-update.log"
HOSTNAME=$(hostname)
TIMESTAMP=$(date "+%Y-%m-%d %H:%M:%S")

echo "========================================" | tee -a "$LOGFILE"
echo "Pi-hole Auto-Update Started" | tee -a "$LOGFILE"
echo "Server: $HOSTNAME" | tee -a "$LOGFILE"
echo "Time: $TIMESTAMP" | tee -a "$LOGFILE"
echo "========================================" | tee -a "$LOGFILE"
echo "" | tee -a "$LOGFILE"

# Run Pi-hole update
echo "Running: pihole -up" | tee -a "$LOGFILE"
pihole -up 2>&1 | tee -a "$LOGFILE"

UPDATE_EXIT_CODE=${PIPESTATUS[0]}
TIMESTAMP_END=$(date "+%Y-%m-%d %H:%M:%S")

echo "" | tee -a "$LOGFILE"
echo "========================================" | tee -a "$LOGFILE"
echo "Pi-hole Auto-Update Completed" | tee -a "$LOGFILE"
echo "End Time: $TIMESTAMP_END" | tee -a "$LOGFILE"
echo "Exit Code: $UPDATE_EXIT_CODE" | tee -a "$LOGFILE"
echo "========================================" | tee -a "$LOGFILE"

# Log to syslog
if [ $UPDATE_EXIT_CODE -eq 0 ]; then
    logger -t pihole-auto-update "[$HOSTNAME] Pi-hole update completed successfully"
else
    logger -t pihole-auto-update "[$HOSTNAME] Pi-hole update failed with exit code $UPDATE_EXIT_CODE"
fi

exit $UPDATE_EXIT_CODE

Deploy:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
# Copy to both servers
scp pihole-auto-update.sh user@<DNS_PRIMARY_IP>:/tmp/
scp pihole-auto-update.sh user@<DNS_SECONDARY_IP>:/tmp/

# Set permissions
ssh user@<DNS_PRIMARY_IP> "sudo mv /tmp/pihole-auto-update.sh /usr/local/bin/ && \
                            sudo chmod 755 /usr/local/bin/pihole-auto-update.sh"

ssh user@<DNS_SECONDARY_IP> "sudo mv /tmp/pihole-auto-update.sh /usr/local/bin/ && \
                              sudo chmod 755 /usr/local/bin/pihole-auto-update.sh"

Why 3 days apart?

If the update on DNS-Primary causes issues, you have 3 days to detect and fix the problem before DNS-Secondary updates to the same broken version. This window gives you time to monitor logs, check for regressions, and roll back if needed.

Step 8: FTL Health Monitoring (Optional)
#

Monitor Pi-hole FTL for exhaustion, rate-limiting, and upstream failures. Sends Discord alerts with 30-minute cooldown.

File: /usr/local/bin/pihole-ftl-monitor.sh (deploy to both servers)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
#!/usr/bin/env bash
set -euo pipefail
#
# Pi-hole FTL Log Monitor
# Detects DNS query exhaustion, rate-limiting, and upstream failures
# Sends Discord webhook alerts with cooldown to avoid alert fatigue
#

# --- Configuration ---
WEBHOOK_URL="https://discord.com/api/webhooks/<YOUR_WEBHOOK_ID>/<YOUR_WEBHOOK_TOKEN>"
FTL_LOG="/var/log/pihole/FTL.log"
STATE_FILE="/var/run/pihole-ftl-monitor.state"
CHECK_WINDOW_MINUTES=5
ALERT_COOLDOWN_SECONDS=1800  # 30 minutes between repeated alerts

# --- Thresholds (within check window) ---
MAX_QUERY_THRESHOLD=1        # Any concurrent query exhaustion = alert
RATE_LIMIT_THRESHOLD=5       # 5+ rate-limit events
UPSTREAM_FAIL_THRESHOLD=10   # 10+ upstream connection failures

HOSTNAME=$(hostname)

count_recent_matches() {
    local pattern="$1"
    local cutoff
    cutoff=$(date -u -d "${CHECK_WINDOW_MINUTES} minutes ago" '+%Y-%m-%d %H:%M')

    if [[ ! -f "$FTL_LOG" ]]; then
        echo 0
        return
    fi

    # FTL.log timestamps: "2026-01-26 21:55:08.414 UTC"
    awk -v cutoff="$cutoff" -v pat="$pattern" '
        substr($0, 1, 16) >= cutoff && index($0, pat) > 0 { count++ }
        END { print count+0 }
    ' "$FTL_LOG"
}

# Count issues in the check window
max_query_count=$(count_recent_matches "Maximum number of concurrent DNS queries reached")
rate_limit_count=$(count_recent_matches "Rate-limiting")
upstream_fail_count=$(count_recent_matches "Connection error")

# Alert if thresholds breached (Discord webhook implementation omitted for brevity)
if [[ "$max_query_count" -ge "$MAX_QUERY_THRESHOLD" ]] || \
   [[ "$rate_limit_count" -ge "$RATE_LIMIT_THRESHOLD" ]] || \
   [[ "$upstream_fail_count" -ge "$UPSTREAM_FAIL_THRESHOLD" ]]; then
    logger -t pihole-ftl-monitor "[$HOSTNAME] DNS health issues detected"
    # Send Discord alert (full implementation in actual script)
fi

exit 0

Add to crontab:

1
2
# /etc/crontab (on both servers)
*/5 * * * * root /usr/local/bin/pihole-ftl-monitor.sh

This monitors for signs of DNS overload or upstream connectivity issues and alerts before they cause failover.

Step 9: Centralized Logging (Optional)
#

If you run Graylog, rsyslog, or another centralized logging system, ship Pi-hole FTL logs for long-term analysis.

File: /etc/rsyslog.d/60-graylog-ftl.conf

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
# Pi-hole FTL Log Forwarding
# Forward FTL WARNING and ERROR logs to centralized logging

module(load="imfile" PollingInterval="10")

# FTL application logs
input(type="imfile"
      File="/var/log/pihole/FTL.log"
      Tag="pihole-ftl"
      Severity="info"
      Facility="local6")

# Forward to Graylog (or your syslog server)
if $syslogtag == 'pihole-ftl' and ($msg contains 'WARN' or $msg contains 'ERROR') then {
    action(type="omfwd" target="<GRAYLOG_IP>" port="1514" protocol="udp")
}

This captures warnings and errors for historical analysis without bloating local disk.

Verification
#

Test 1: Check Which Server is MASTER
#

Pi-hole dashboard showing DNS query statistics and blocked queries

1
2
3
4
5
# Should show VIP on primary
ssh user@<DNS_PRIMARY_IP> "ip addr show eth0 | grep <DNS_VIP>"

# Should show nothing on secondary
ssh user@<DNS_SECONDARY_IP> "ip addr show eth0 | grep <DNS_VIP>"

Test 2: Manual Failover Test
#

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
# Stop Pi-hole on primary
ssh user@<DNS_PRIMARY_IP> "sudo systemctl stop pihole-FTL"

# Wait 15 seconds (3 × 5 second health checks)
sleep 15

# Check VIP moved to secondary
ssh user@<DNS_SECONDARY_IP> "ip addr show eth0 | grep <DNS_VIP>"

# Check Discord - should show:
# - Primary: FAULT state
# - Secondary: MASTER state

# Test DNS still works
dig @<DNS_VIP> google.com

# Restore primary
ssh user@<DNS_PRIMARY_IP> "sudo systemctl start pihole-FTL"

# Wait 10 seconds (2 × 5 second rise checks)
sleep 10

# Check VIP returned to primary
ssh user@<DNS_PRIMARY_IP> "ip addr show eth0 | grep <DNS_VIP>"

Test 3: DNS Query Works via VIP
#

1
2
3
4
# From your workstation
dig @<DNS_VIP> example.com

# Should return DNS resolution without errors

Test 4: Keepalived Logs
#

1
2
3
4
# Check state transitions
ssh user@<DNS_PRIMARY_IP> "sudo journalctl -u keepalived --since '1 hour ago' | grep -i transition"

# Expected output shows MASTER/BACKUP transitions

Troubleshooting
#

Symptom	Cause	Fix
VIP not appearing on primary	`virtual_router_id` mismatch	Verify both configs use same VRID (e.g., 55)
VIP appears on both servers	Firewall blocking VRRP	Allow protocol 112 (VRRP) on firewall
Frequent failover (flapping)	Health check timeout too aggressive	Increase `timeout` from 2→5 seconds
No failover when primary stops	Weight calculation wrong	Verify weight -150 drops priority below secondary’s 100
Discord notifications not working	Webhook URL incorrect	Test webhook with curl manually
Health check always failing	DNS resolution broken on Pi-hole itself	Check `/etc/resolv.conf` points to gateway, not 127.0.0.1
VIP appears but DNS doesn’t work	Firewall blocking VIP traffic	Ensure firewall allows traffic to VIP address
keepalived won’t start	Syntax error in config	Run `keepalived -t -f /etc/keepalived/keepalived.conf`

Common keepalived issues:

“Configuration is using : 0 Bytes” - This is GOOD. Config is valid.
“VRRP_Instance(DNS_HA) Entering FAULT STATE” - Health check failed. Check /var/log/syslog for keepalived-healthcheck messages.
Both servers show MASTER - VRRP multicast blocked. Use unicast_peer (as shown in configs above) to avoid multicast dependency.

Lessons from Production
#

I’ve been running this HA DNS setup for months in production. Here are the hard-learned lessons:

Memory Matters
#

Mistake: Started with 512MB RAM per container.

Problem: Pi-hole’s FTL database grew to 700MB+ with 61-day retention, causing I/O stalls and health check timeouts.

Fix:

Upgraded containers to 1GB RAM minimum
Reduced database retention to 3 days (ship long-term logs to Graylog)
Monitor available memory, alert if < 200MB

Lesson: Pi-hole FTL database size grows with query volume × retention days. Budget RAM accordingly.

Health Check Timeout Tuning
#

Mistake: Initial health check timeout was 500ms.

Problem: Spurious failovers every 15-20 minutes when Pi-hole briefly lagged under load.

Fix:

Increased timeout from 0.5s → 1.0s
Increased interval from 2s → 5s
Changed fall from 2 → 3 (now requires 15 seconds of consecutive failures)

Lesson: Health checks must tolerate brief performance hiccups. Use conservative timeouts and multiple failure threshold.

DNS Resolution Circular Dependency
#

Mistake: DNS-Primary used DNS-Secondary for DNS, DNS-Secondary used DNS-Primary for DNS (circular dependency).

Problem: When one server rebooted, the other couldn’t resolve DNS during gravity updates → 12+ minute failures → cascading outage.

Fix: Both servers now use gateway/firewall (which has static DNS entries) as primary DNS, Cloudflare 1.1.1.2 as fallback. Neither depends on the other.

Lesson: HA pairs should never depend on each other for critical services. Use external/upstream dependencies.

Never Use Multiline Output in Health Checks
#

Mistake: Health check used grep without -q flag.

Problem: Multiline output broke keepalived’s state machine → constant FAULT state.

Fix: Changed all grep to grep -q (quiet mode, returns only exit code).

Lesson: Health check scripts must return only exit code 0 or 1. Any stdout/stderr output can break keepalived.

FTL Database Retention vs. Centralized Logging
#

Mistake: Kept 30-day local database retention “just in case.”

Problem: 1GB+ database files caused slow queries, high I/O, health check timeouts.

Fix:

Reduced retention to 3 days (enough for Pi-hole web dashboard)
Ship DNS query logs to Graylog (30-90 day retention, indexed, searchable)
Freed up 800MB disk space and eliminated I/O pressure

Lesson: Use centralized logging for long-term DNS analytics. Keep local retention minimal.

Gravity Updates Can Cause Circular DNS Dependency
#

Mistake: Pi-hole servers using 127.0.0.1 for DNS resolution during gravity updates.

Problem: Gravity update downloads blocklists → requires DNS → queries itself → deadlock.

Fix: Configure Proxmox LXC containers to set /etc/resolv.conf to gateway IP, not localhost.

Lesson: Pi-hole cannot be its own upstream DNS. Always use external resolver for the Pi-hole server itself.

512MB RAM is Insufficient
#

Mistake: Assumed Pi-hole is “lightweight” and allocated 512MB.

Problem: OOM killer terminated processes when FTL database grew beyond 500MB.

Fix: 1GB RAM minimum. More if you have high query volume (>100K queries/day).

Lesson: Memory usage = FTL database + buffers + OS overhead. Monitor with free -h and alert if available < 200MB.

Duplicate CNAME Files Break Pi-hole v6
#

Mistake: Created CNAME records in /etc/dnsmasq.d/*.conf files AND in pihole.toml.

Problem: Pi-hole v6 loads CNAMEs from both locations → duplicate CNAME errors → dnsmasq fails to start → DNS outage.

Fix: Use only pihole-FTL --config to manage CNAMEs. Delete all dnsmasq.d/*.conf CNAME files.

Lesson: Pi-hole v6 changed CNAME management. Never manually create dnsmasq.d config files for CNAMEs.

What I Learned
#

High Availability Doesn’t Mean Zero Downtime
#

Failover takes 15 seconds (3 consecutive health check failures). During that window, DNS queries time out. Design for resilience, not perfection. 15 seconds of DNS unavailability is acceptable when it prevents hours of manual recovery.

Monitoring is as Important as Redundancy
#

Without Discord notifications, I wouldn’t know failover occurred until I checked logs. Real-time alerts turn HA from “set and forget” to “observe and optimize.”

Start Conservative, Tune Based on Reality
#

Initial health check settings (0.5s timeout, 2-failure threshold) caused flapping. Production data showed that 1.0s timeout with 3-failure threshold eliminated false positives. Trust your metrics, not your assumptions.

Stagger Everything
#

Updates, backups, maintenance windows — never do both servers simultaneously. The 3-day update stagger saved me when a Pi-hole update introduced a regression that broke DNSSEC. Primary got the broken version, I caught it in logs, held back secondary’s update.

Simplicity Wins
#

I considered adding Consul for health checks, Prometheus for metrics, Ansible for config management. Instead: keepalived (simple, battle-tested, built-in health checks), bash scripts (readable, auditable), rsyslog (ubiquitous). Fewer dependencies = fewer failure modes.

Test Failover Regularly
#

I manually trigger failover monthly to verify it works. You don’t want to discover your HA setup is broken during an actual outage.

Documentation is for Future You
#

Six months from now, you won’t remember why you set weight -150 instead of -100. Document the math. Explain the rationale. Your future self will thank you.

Conclusion
#

You’ve built a production-grade high-availability DNS infrastructure with:

Automatic failover in under 15 seconds
Health monitoring that detects actual failures, not noise
Discord notifications for real-time visibility
Staggered updates to prevent simultaneous outages
Centralized logging (optional) for long-term analytics

DNS is now resilient to server failures, LXC host reboots, power outages, and failed updates. Your homelab gained a critical reliability layer.

Next steps:

Monitor Discord for the first week — verify no spurious failovers
Manually trigger failover monthly to ensure it works
Check FTL database size weekly (du -sh /etc/pihole/pihole-FTL.db)
Review health check logs for false positives
Consider adding Uptime Kuma or similar external DNS monitoring

Resources:

Keepalived documentation: https://www.keepalived.org/manpage.html
Pi-hole FTL docs: https://docs.pi-hole.net/ftldns/
VRRP RFC 3768: https://datatracker.ietf.org/doc/html/rfc3768

Your homelab DNS just became bulletproof. Go break something — your Pi-hole will survive it.

Homelab Security - This article is part of a series.

Part : This Article

Part : Protecting Vaultwarden Behind Caddy with Cloudflare Proxy

Overview#

Prerequisites#

Architecture Diagram#

Step 1: Install Keepalived#

Step 2: Create Health Check Script#

Step 3: Configure Keepalived (Primary)#

Step 4: Configure Keepalived (Secondary)#

Step 5: Discord Notifications (Optional)#

Step 6: Start Keepalived#

Step 7: Stagger Automated Updates#

Step 8: FTL Health Monitoring (Optional)#

Step 9: Centralized Logging (Optional)#

Verification#

Test 1: Check Which Server is MASTER#

Test 2: Manual Failover Test#

Test 3: DNS Query Works via VIP#

Test 4: Keepalived Logs#

Troubleshooting#

Lessons from Production#

Memory Matters#

Health Check Timeout Tuning#

DNS Resolution Circular Dependency#

Never Use Multiline Output in Health Checks#

FTL Database Retention vs. Centralized Logging#

Gravity Updates Can Cause Circular DNS Dependency#

512MB RAM is Insufficient#

Duplicate CNAME Files Break Pi-hole v6#

What I Learned#

High Availability Doesn’t Mean Zero Downtime#

Monitoring is as Important as Redundancy#

Start Conservative, Tune Based on Reality#

Stagger Everything#

Simplicity Wins#

Test Failover Regularly#

Documentation is for Future You#

Conclusion#

Overview
#

Prerequisites
#

Architecture Diagram
#

Step 1: Install Keepalived
#

Step 2: Create Health Check Script
#

Step 3: Configure Keepalived (Primary)
#

Step 4: Configure Keepalived (Secondary)
#

Step 5: Discord Notifications (Optional)
#

Step 6: Start Keepalived
#

Step 7: Stagger Automated Updates
#

Step 8: FTL Health Monitoring (Optional)
#

Step 9: Centralized Logging (Optional)
#

Verification
#

Test 1: Check Which Server is MASTER
#

Test 2: Manual Failover Test
#

Test 3: DNS Query Works via VIP
#

Test 4: Keepalived Logs
#

Troubleshooting
#

Lessons from Production
#

Memory Matters
#

Health Check Timeout Tuning
#

DNS Resolution Circular Dependency
#

Never Use Multiline Output in Health Checks
#

FTL Database Retention vs. Centralized Logging
#

Gravity Updates Can Cause Circular DNS Dependency
#

512MB RAM is Insufficient
#

Duplicate CNAME Files Break Pi-hole v6
#

What I Learned
#

High Availability Doesn’t Mean Zero Downtime
#

Monitoring is as Important as Redundancy
#

Start Conservative, Tune Based on Reality
#

Stagger Everything
#

Simplicity Wins
#

Test Failover Regularly
#

Documentation is for Future You
#

Conclusion
#
